SW2343-M High Polishing Mirror Plastic Mold Steel

Specification: 200mm-600mm

Product characteristics

SW 2343-M is a medium carbon high alloy steel with qualities such as high purity, high isotropy, high polishability and excellent machinability,with the following characteristics:

• Very low content of non-metallic inclusions and gases, high purity. The steelmaking is based on high-purity and high-quality blast furnace hot metal. With low S and low P alloying material and LF+RH vacuum cycle degassing refining process for smelting, the material purity is guaranteed.
• Uniform hardness and structure, and excellent polishing performance. NADCA# standards are adopted to strictly control the internal quality of the steel, so as to meet the requirements of the material such as high polishability, etc.
• High strength and toughness, and excellent machinability, The hardness and toughness of the material are guaranteed by the optimization of alloy composition, the latest multi-directional forging process and professional heat treatment process, and the service life is better than similar traditional mold materials.

Process features:

• Blast furnace hot metal + RH vacuum cycle degassing technology;
• Advanced multi-directional forging technology, with a forging ratio greater than 6
• High temperature homogenization + structure super-fining technology

Product applications:

• Plastic hard mold, pouring mold
